Autel MaxiCOM MK906S Pro
The MaxiCOM MK906S PRO is an advanced smart wireless diagnostics device providing specialized automotive diagnostic service for workshop and home-use customers. Based on the multitasking mobile operating system, and combined with the best possible coverage of OE-level diagnostics, the MK906S Pro performs comprehensive and efficient vehicle diagnostics and analysis.
Upgraded of older MK906 Pro version ,2023 New MK906S Pro bring you a brand-new experience at the same cost.✅8.0-inch TFT-LED Screen✅faster Android 10✅larger 4+128GB memory✅2.4G & 5G dual Wi-Fi ✅NO IP-block✅Long-lasting 11,600 mAh battery✅16 MP front and rear camera✅Wireless MaxiVCI V200 ✅Advanced ECU coding✅36+ reset service✅OE-level full system diagnosis
Advanced ECU Coding
Autel MK906S Pro professional auto diagnostic tool comes with advanced ECU coding function. ECU Coding allows you to establish a data link to the ECU via the VCI device for vehicle diagnosis, service or coding. You can enable or disable certain features or functions in a vehicle. enhanced control over their vehicles, allowing them to customize features, improve performance, and adapt the vehicle to their specific needs.
Accessing Manufacturer-Specific Codes: Provide access to manufacturer-specific codes, allowing users to perform coding functions that are specific to particular vehicle makes and models. This includes accessing hidden features or customizing various parameters within the ECU.
Enabling/Disabling Vehicle Options: Users can enable or disable specific options or features within a vehicle. For example, they can activate or deactivate functions like auto-locking doors, daytime running lights, or seat belt reminders. This level of customization allows users to tailor their vehicle's behavior according to their preferences.
Performance Tuning: Offer performance tuning capabilities, allowing users to enhance the performance of their vehicles. This includes adjusting engine parameters, such as fuel-to-air ratio, ignition timing, boost pressure, or throttle response. By optimizing these settings, users can improve power output, fuel efficiency, or overall driving experience.
Coding Retrofits: Support coding retrofits, which means users can add new components or modules to their vehicles and code them into the existing ECU. For example, if a user wants to install aftermarket headlights, they can code the ECU to recognize and control the new headlights properly.
OE-Level Full System Diagnosis
MK906S Pro can Read and Erase Codes on all available vehicle systems,Exceptional OE-Level system coverage for all electronic systems,View Freeze Data and view and graph Live Data, Compatible with U.S., European vehicles, 1996 and newer.
Read Codes: This function retrieves and displays the DTCs from the vehicle’s control system. The Read Codes screen varies for each vehicle being tested. On some vehicles, freeze frame data can also be retrieved for viewing.
Erase Codes: After reading the retrieved codes from the vehicle and certain repairs have been carried out, you can decide to erase the codes from the vehicle using this function.
Live Data:This function displays the real time PID data from ECU. Displayed data includes analog inputs and outputs, digital inputs and outputs, and system status information broadcast on the vehicle data stream.
36+ Reset Services
Autel MaxiCOM MK906S Pro, bluetooth scanner is loaded with 31+ reset functions for in-depth and comprehensive repairing & maintenance.
Oil Reset - Reset the oil change calculator in the engine and automatic transmission
EPB - Replacement of brake pads on vehicles with an electric parking brake
SAS - Adaptation of the sensor to the angular position of the steering wheel
DPF - Regeneration of diesel particulate filter
Brake Bleed - ABS Brake Bleeding
BMS - Battery registration and reset
- Seats, Odometer, Injector, CHG tire size, TEC Learn, Suspension, Throttle, WIN OR ROOF, Lang Change, Headlamp.
Note: The reset service does not work normally on all vehicles. In order to ensure that the Autel diagnostic tool can solve the problems you encounter, please provide the VIN of your vehicle and your needs, and we will reply to you an email within one working day. 👉Contact us👈
Bi-Directional Control (Active Test)
MaxiCOM MK906S Pro automotive diagnostic scanner comes with bi-directional control capability to perform active tests to determine the integrity of a system or parts like ABS, window, door, roof, by reading the ECU data, or by monitoring the operation of the actuators, such as switching a solenoid, relay.
MaxiCOM MK906S Pro is a diagnostic scanner with various interfaces that can access to more Add-on like Inspection Camera, HDMI Projector, Phone, PC, USB Memory Stock, Headset, Oscilloscope, Extend SD Card etc.
Digital Inspection: MK906S Pro connects to a MV108S inspection camera and turns into a video inspection scope, allowing you to examine difficult-to-reach areas normally hidden from sight. It is capable of recording digital still images and videos, which offers you an economical solution to inspect machinery, facilities, and infrastructure in a safe and quick way.
Battery Test: Autel automotive tool MK906S Pro works with Battery Tester BT506 to check 12V vehicle battery and view the health status of the vehicle's battery and electrical system.
Top 7 Highlights
No Blocking - You can use MK906S Pro all over the world
Top-Level Hardware -Androis 10.0 version, Octa-core processor; 4G RAM/128G ROM; 8.0" LED; Front: 16 Megapixel/Rear: 16 Megapixel; 11600 mAh battery capacity.
OE-Level Full Systems Diagnosis - MaxiCOM MK906S Pro can get OE-level analysis of ECM, transmission, ABS, airbag, SAS, DPF, EVAP, TPMS, BMS, EPB among other on-board systems. You can read, clear their codes thus turning off warning lights; check freeze frame data and view live stream in graph to evaluate the vehicle’s health at a glance.
36+ Service Functions - MK906S Pro has 36 service function options, mainly including Oil Reset, EPB service, TPMS ID Relearn, ABS Auto Bleed, SAS Calibration , DPF Regeneration and etc
Battery Tester - Autel automotive tool MK906S Pro works with Battery Tester Autel BT506 to check 12V vehicle battery and view the health status of the vehicle's battery and electrical system.
1-Year Free Software Update - After you register and log in, you can enjoy a free software upgrade for one year. After one year, if you do not choose to continue to purchase the upgrade service, it will not affect the normal use of the device
DoIP/CAN & CAN FD Latest Protocol - MK906S Pro now supports oIP/CAN & CAN FD Protocol. You no longer need to buy a separate adapter.
Autel Cloud Service - MaxiCOM MK906S Pro supports Autel Cloud Service, including remote expert service, one click help, device management/report management, intelligent and comprehensive.
- Support Multi-Language: English, French, German, Spanish, Portuguese, Dutch, Polish, Swedish, Korean, Japanese, Russian, Italian
Autel MaxiCOM MK906S Pro Main Features
- 8-inch, 1920 x 1200 high-resolution touchscreen tablet, Samsung Exynos Octa-core processor with 128 GB storage and running Android 10.0 operating system.
- Long-lasting 11,600 mAh rechargeable battery, 16 MP front camera and 16 MP rear camera.
- MaxiCVI V200 wireless Bluetooth vehicle communication interface supporting the latest communication protocols.
- Comprehensive diagnostics on 1996 and newer U.S., Asian and European vehicles
- AutoScan: Scan all available systems
- Read/Erase Codes, View Freeze Frame and Live Data
- Perform Active Tests (bi-directional controls), Coding and Adaptations
- AutoVIN/Scan VIN for rapid vehicle identification
- Perform ADAS (inc. Camera/s, Radar, LiDAR, Night Vision) Systems Calibrations with additional purchase.
- Battery analyzation capability*
- Cloud-based Reports and Data Management
- Remote Expert (coming soon)
- With additional purchase of the MaxiBAS BT506 battery and electrical system tester.
Autel MaxiCOM MK906S Pro Specification:
Octa-core processor (2.2 GHz Qual high, performance Kryo cores + 1.8 GHz Qual low, power Kryo cores)
||4G RAM/ 128GB ROM
||8.0" LED capacitive touch screen with 1920x1200 resolution
||• Wi-Fi (802.11 b/g/n)USB: 2.0, Mini USB 2.0 Wireless BT V2.1+EDR Class1, HDMI 1.4a SD Card (support up to 32 GB)
Front: 16 Megapixel
Rear: 16 Megapixel
||Gravity Accelerometer, Ambient Light Sensor (ALS)
||• Microphone • Single Speaker • 3-Band 3.5 mm stereo/standard headset jack
|Power and Battery:
||11600 mAh 3.7 V lithium-polymer battery
Charging via 12 V AC/DC power supply
||12 V (9-35 V)
||-10 to 55°C (14 to 131°F)
||-20 to 70°C (-4 to 158°F)
|Dimensions (W x H x D):
||270.8 mm (10.0”) x 176.0 mm (6.9”) x 36.0 mm (1.4”)
||NW: 1.05 kg (2.3lb.)
Autel MaxiCOM MK906S Pro Package List
- 1x MaxiCOM MK906S Pro main unit
- 1x MaxiVCI V200
- 1x AC/DC Adapter (12V)
- 1x Type C USB Cable
- 1x Cigarette Lighter Adapter
- 2x Spare Fuse(6*30mm)
- 1x USB to Ethernet Adapter
- 1x Soft Cloth
- 1x User Manual
- 1x Packing List
- 1x Carrying Case
- 1x Quick Reference Guide
Q: What's the difference between MK906S pro and MS906 pro?
A: For hardware,CPU: mk906S pro is Qualcomm 660,ms906 pro is Exynos 8895.
Language : mk906S pro is multi-language ,but ms906 pro is only English.
Diagnosis：Only difference is that ms906 pro can do oscilloscope with autel mp408,but mk906S pro cann't.
A: 1 Year
Q：Free softeare update?
A:1 Year.If you don't update after 1 year ,it still can work normally,just cann't update to latest function.
Q：How much will cost after one year free update?
A:Right now ,the one year price for mk906S pro update is €360
Q：Can i put my company info on invoice?
A:Yes,we can put info as your request
A:Yes,lifetime,we can provider technical support from autel official
Q:Can i use this machine with my language?
A:This is multi-language ,support: English,German, Spanish, Portuguese,French, Polish, Italian, Japanese etc.
Q:How to change language?
A:Please send us your machine S/N number (on the machine back),and after we add language ,please make sure update all software in this language version.
