Autel MaxiCOM Ultra Lite S
2023 Newest intelligent diagnostic tablet, MaxiCOM Ultra Lite S Provides full functions and on-line repair information needed when diagnosing vehicles, identifying faults and researching repairs.
As an intelligent diagnostics and information system, MaxiCOM Ultra Lite S not only displays the relevant repairs cases gathered from experienced industry experts, but provides step-by-step guidance to ensure the repair is done correctly and efficiently.
Autel MaxiCOM Ultra Lite S Intelligent Diagnosis
As the most ambitious tablet scanner developed by Autel, The Autel MaxiCOM Ultra Lite S is designed to diversify the knowledge pool of repairers, simplify the diagnostic process and bring out the maximum potential of each technician.
The newly added Repair Assist and TSB can consolidate and prioritize all detected fault codes and present in topology diagram. And also, it provides repair tips, videos, and related cases for your reference.
The following are main parts of the code data contained in Intelligent Diagnostics:
- Technical Service Bulletin (OEM Information).
- DTC Analysis.
- Repair Assist.
- Repair Tips.
- Relevant Cases
One-Stop Intelligent Diagnosis With Topology Mapping, Helping You Have a Clear Picture of Vehicle Status; For each fault code, Ultra Lite performs in-depth analysis and gives the OE data and processing suggestions.
Autel MaxiCOM Ultra Lite S Advanced Functions:
ECU Programming/ECU Coding - Autel advanced diagnostic scanner Ultra comes with J2534 ECU programming device BMW Ethernet Cable(For F-Series Coding Programming), which is capable of replacing the existing software/firmware in the Electronic Control Units (ECU), programming new Benz/BMW ECUs and fixing software-controlled drivability issues and emission issues, update the computer software on the vehicle to the latest version.
Note: ECU Programming only for BMW/Mercedes Benz
Autel MaxiCOM Ultra Lite S Full Systems Diagnosis
Doing regular and routine maintenance on a modern car is impossible without a diagnostic system. Even the simplest procedures require the participation of an auto scanner. That's why Autel engineers have been working on them and making them as user-friendly as possible in the new MaxiCOM Ultra Lite S. Now you can easily do functions like:
Oil Reset: Reset the oil change calculator in the engine and automatic transmission
EPB: Replacement of brake pads on vehicles with an electric parking brake
SAS: Adaptation of the sensor to the angular position of the steering wheel
DPF: Regeneration of diesel particulate filter
Brake Bleed: ABS Brake Bleeding
IMMO: Disable any lost keys and add new keys. *ONLY for vehicles with low-grade anti-theft systems. Compatible with GM, Ford, Toyota, Honda and other 56 brands or models.
TPMS: Battery registration and reset
Seat Calibration: Calibrate the memory in replaced or repaired seats
Airbag Reset: Resets the airbag data to clear the airbag collision fault indicator
A/F Reset: Set or learn Air/Fuel ratio parameters
Gearbox Reset: Help complete the gearbox self-learning to improve gear shifting quality
Suspension Reset: Adjust the vehicle body height sensor for level calibration
BMS: Battery registration and reset
Bi-directional Control (Active Test) - Ultra automotive diagnostic scanner comes with bi-directional control capability to perform active tests to determine the integrity of a system or parts like ABS, window, door, roof, by reading the ECU data, or by monitoring the operation of the actuators, such as switching a solenoid, relay.
Note: Available tests vary depending on the manufacturer, year, and model, and only the available tests display in the menu. To check compatibility with your vehicle, please refer to Autel website or consult us directly.
Why Choose Autel MaxiCOM Ultra Lite S ?
No IP Restriction - You can use MaxiCOM Ultra Lite S in any region.
- 2 Years Free Update: Original free update is 1 year ,now we send 1 year more! Total 2 years free update,Save over €1000 for update!
Latest Update Version - More advanced and powerful diagnostic tools are not affected by IP restrictions and can be used all over the world
Intelligent Diagnostics & 36+ Services - Through one-stop Intelligent Diagnostics, Autel Scanner MaxiCOM Ultra Lite S provides techs with step-by-step repair guidance. With multiple repair guidance options: Technical Service Bulletin, DTC Analysis, Repair Assist, Repair Tips, Component Measurement, and Relevant Cases, it can make your work 200% easier than ever. Also, it has 36+ service to help you win more business.
99% Coverage on the Market - Autel MaxiCOM Ultra Lite S supports over 80+ US , European and Asian vehicles. The Ultra has the best newer vehicle coverage , 95% of post 2000 vehicles, and 85% of post 2019 vehicles and it’s fast growing with the frequent released software updates.
Solid Hardware & Software- Ultra Lite S With a winning combination of hardware and software, the Autel MaxiCOM Ultra Lite S ensures you a smooth and efficient diagnostic experience. Android 7.0 OS, Samsung octa-core processor, 4GB RAM & 256GB memory, 12.9 inch TFT-LCD touch screen, front & rear cameras, 18000mAh 3.8 V battery, etc.
- 1 Year Warranty
Multi-Language: English/French/Spanish/Portuguese/German/Polish/Italian/ Dutch/Russian/Japanese/Korean
Note: Machine default language is English,If you want to activate other language ,Please send us the S/N number after you receive the machine.
Autel MaxiCOM Ultra Lite S Main Features
- Large 12.9" Touchscreen (2732 x 2048) / Android 7.0
- 2.3GHz + 1.7GHz Octa-core Processor / 256GB Memory
- Oscilloscope Preset Guided Component Tests / Waveform Library
- New VCI Protocols: D-PDU, DoIP/CAN FD, Mega CAN
- Split Screen Multi-Application Function / Dual Wi-Fi Connection
- Topology Module Mapping: Color Coded All System Status Screen (on supported vehicles)
- Relevant Cases: DTC Troubleshooting / Repair Tips Video Library
- Repair Assist: Guided Procedures with DTC Analysis Fault Code Solutions
- Code-Related Technical Service Bulletins (on select vehicles) / License Plate Reader
- ScanVIN: Barcode or Text Recognition with Camera
- Secure Gateway Access: Authorized FCA SGM Access with AutoAuth Account
- Includes Docking Station, Cables, Scope Connectors, Carrying Case, 1YR Warranty Software Subscription
- Enhanced Diagnostic Reports: PreSCAN PostSCAN
- 18000mAh - 8hrs Continuous Use / 16MP Rear Camera 16MP Front Camera
Autel MaxiCOM Ultra Lite S Detail Display:
Autel MaxiCOM Ultra Lite S Specification:
||Samsung Exynos8895V octa-core Processor (2.3GHz Quad-core Mongoose + 1.7GHz Quad-core A53)
||4GB RAM 256GB On-board Memory
||12.9 inch TFT-LCD with 2732 x 2048 resolution capacitive touch screen
||WiFix2 (802.11 a/b/g/n/ac 2x2 MIMO),BT v.2.1 + EDR,GPS
USB 2.0 (Two USB HOST Type A, one USB mini device),HDMI 2.0,SD Card (Support up to 256GB)
||Rear: 16 Megapixel, Autofocus with Flashlight
Front: 5 Megapixel
||Gravity Accelerometer, Ambient Light Sensor (ALS)
||Microphone,Dual Speakers,3-Band 3.5 mm stereo/standard headset jack
|Power and Battery:
||18000mAh 3.8 V lithium-polymer battery
Charging via 12 V AC/DC power supply with the temperature between 0°C and 45°C
||0 to 50°C (32 to 122°F)
||-20 to 60°C (-4 to 140°F)
|Dimensions (W x H x D):
||366.5 mm (14.43") x 280.9 mm (11.06") x 34 mm (1.34")
||2.18kg (4.81 lb.)
||DoIP, PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 Single Wire Can (GMLAN), ISO-11898-2, ISO-11898-3, SAE-J2819 (TP20),
TP16, ISO-9141, ISO-14230, SAE-J2610 (Chrysler SCI), UART Echo Byte, SAE-J2809 (Honda Diag-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD BUS),
Ford UBP, Nissan DDL UART with Clock , BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708, SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2)
Autel MaxiCOM Ultra Lite S Package List:
- 1x MaxiCOM Ultra Lite S Main Unit
- 1x MaxiFlash VCI
- 1x Docking Station
- 1x Main Cable V2.0
- 1x USB 2.0 Cable V2
- 1x AC/DC Adapter(12V)
- 1x Auxiliary Power Outlet Adapter
- 2x Spare Fuse 6x30mm
- 1x Clamp Cable
- 1x USB to Enthernet Adapter
- 1x Quick Reference Guide
- 1x Packing List
- 1x Soft Cloth
- 1x Carrying Case 650 x 185 x 430 mm
Q: What's the difference between Autel Ultra Lite S and Autel Ultra?
A: The machine hardware and diagnosis function are almost the same.But here are the difference:
1、VCI: Autel ultra with Maxiflash VCMI,Which means ultra can do oscilloscope/multimeter/waveform/can bus check. And Ultra lite S with Maxiflash VCI,did not support these functions.
2、Language :Autel Ultra Lite S support multi-language(English/French/Spanish/Portuguese/German/Polish/Italian/ Dutch/Russian/Japanese/Korean etc.) ,but Autel Ultra only support English
Q: If I buy a product, where will it be shipped from? Do I need to pay any other fees?
A: We have France, Germany, Spain and other warehouses in Europe. If you are located in the EU, the products will be dispatched from the local warehouse, the logistics time is 3-5 days, you don't need to pay other fees.
Q: Warranty ？
A: 1 Year
Q: When does the 2-year free upgrade start to count? Will normal use be affected if I do not purchase the upgrade service after one year?
A: The 2-year free upgrade service for each device starts when you register and log in to your account, and you can check the expiration time in the settings. After 2 years, if you do not continue to purchase the upgrade service, it will not affect your normal use of Autel devices, but you will not be able to update the latest upgraded functions.
Q: Technical support?
A: Yes,lifetime,we can provider technical support from autel official
Q: How to change language?
A: After you receive the package ,please send us the S/N number(on the machine back),and we will activate other language within 1 day(except weekends)
Q: How can I make sure the product will work properly in my vehicle? If something goes wrong, can I return it?
A: Our products can be used on any OBD2 compliant vehicle, with the difference that partial reset services and advanced features are only available on some brands of vehicles. So, to ensure your shopping experience, please send the VIN of your vehicle and your needs to our Email--👉Contact us👈, we will reply you within one working day.
